Email this article Beam forming network on the base of non-identically coupled transmission lines
- Authors: Bankov S.Е.1
-
Affiliations:
- Kotel’nikov Institute of Radioengeneering and Electronics RAS
- Issue: Vol 70, No 1 (2025)
- Pages: 3-11
- Section: ЭЛЕКТРОДИНАМИКА И РАСПРОСТРАНЕНИЕ РАДИОВОЛН
- URL: https://edgccjournal.org/0033-8494/article/view/684116
- DOI: https://doi.org/10.31857/S0033849425010013
- EDN: https://elibrary.ru/HJXBKI
- ID: 684116
Cite item
Open Access
Access granted
Subscription Access
Abstract
Beam forming network as a system of parallel coupled transmission lines with different coupling coefficients is proposed. The beam forming network feeds linear array that in its turn forms radiation pattern with sector shape. An eigenwave problem for an infinite system of infinite transmission lines is solved in frame of coupled wave theory. Also a problem of eigenwave excitation is solved in frame of the same theory. Relations describing wave amplitudes in output plane are obtained. Directivity multiplier of a linear radiating array that excited by the waves in the output plane is considered. The analysis demonstrates that application of new type beam forming network sufficiently improves radiation pattern shape in compare with radiation pattern of the array with beam forming network with identically coupled transmission lines.
About the authors
S. Е. Bankov
Kotel’nikov Institute of Radioengeneering and Electronics RAS
Author for correspondence.
Email: sbanlkov@yandex.ru
Russian Federation, Mokhovaya St., 11, build. 7, Moscow, 125009
References
- Cкобелев С.П. Фазированные антенные решетки с секторными парциальными диаграммами направленности. М.: Физматлит, 2010.
- Bankov S.E., Bugrova T.I. // Microwave and Optical Technology Lett. 1993. V. 6. P. 782.
- Банков С.Е., Калошин В.А., Фролова Е.В. // Журн. радиоэлектроники. 2009. № 3. http://jre.cplire.ru/jre/mar09/1/text.html
- Банков С.Е., Грачев Г.Г., Дупленкова М.Д. // РЭ. 2012. Т. 57. № 6. С. 613.
- Банков С.Е. // РЭ. 2009. Т. 54. № 10. С. 1157.
- Унгер Г.Г. Оптическая связь. М.: Связь. 1979.
- Амитей Н., Галиндо В., Ву Ч. Теория и анализ фазированных антенных решеток. М.: Мир. 1974.
- Унгер Х.Г. Планарные и волоконные оптические волноводы. М.: Мир, 1980. С. 231.
- Cкобелев С.П. // Радиотехника. 2013. № 5. С. 74.
